Homelift, Load 320KG-1600KG, Speed 0.4-1.0m/s

Homelift, Load 320KG-1600KG, Speed 0.4-1.0m/s

    • small.img.alt
    • small.img.alt
    • small.img.alt
  • large.img.alt

    Product Details:

    Place of Origin: CHINA
    Brand Name: FUJI
    Certification: GB98
    Model Number: FE-H

    Payment & Shipping Terms:

    Minimum Order Quantity: 1unit
    Price: Negotiable
    Packaging Details: Standard export package
    Delivery Time: 15-35 days upon order approved
    Payment Terms: T/T, L/C
    Supply Ability: 1000//month
    Contact Now
    Detailed Product Description

    Luxury 4 Persons Home Lift Elevators , Automotive Indoor Villa Lift



    Overview

    FUJI villa elevator adheres to the top-tech in the world’s private elevator field. It inherits the classical international design concept and deducts a luxurious dream in your home art. It grants a full play of an overall supreme quality at your home.

    FUJI villa elevator integrates the art, pragmatism and the character of time into one. The machine room-less elevator enhances the degree of freedom to the architectural design. It is safe and reliable from the pit-less and run-through doors design. It is the most ideal up and down transport tool for the aged, the sick, and the handicapped. The pleasing decoration invents a overall harmonious effect to the indoor decoration. The highly efficient traction machine is integrated with variable voltage, variable frequency control and microprocessor control technology of high speed processing capability for accurate transmission of FUJI villa elevator enable your family enjoy smoother, securer and more comfortable service.

    FUJI creates a clean and bright space which perfectly matches into harmony of your home. It adds more of the elevator interest and fulfills your villa elevator dream. FUJI villa elevator lets you fully enjoy the wonderful life.



    Excellent Performance

    1.More efficient use of building space: machine room-less innovative design, compact arrangement and space-saving, installation in any building without Hoistway.
    2. Pleasing decoration: thorough car design, the rich material and a diversified combination
    3. Safety and comfort & Environmental protection: maintenance-free and non-pollution permanent magnet synchronous and gearless traction machine
    4. High efficiency, energy saving, comfort: 220V normal voltage, 1.1KW low energy consumption, variable voltage and variable frequency door governor system, low noise and low vibration, reasonable design of air conditioner
    5. Easy and simple operation: the multiple door open modes for the users
    6. The humane interface design: touch type operation button with the concise and eye-catching control panel, a service button, emergency stop button and an alarm button.



    Standard Function

    NO.

    Function Name

    Descriptionof functions

    1

    Maintenance
    operation

    Elevator access to the overhaul state, the system automatically canceled and the operation of automatic doors. By the upper (lower) line will enable the elevator button to overhaul the speed of movement of the point (down) operation. Release the button to stop the lift immediately.

    2

    The best curve
    generated
    automatically

    Systems automatically computing the most suitable for the principle of human-machine function curve according to the distance needed to run, and is not subjected to restrictions on short floor and the number of constraints.

    3

    Fire back to the base station

    Receive the fire signal, the elevator will not respond to any calls and inside command. The elevator run the fastest way to the fire station and then open the door and stop.

    4

    Automatic back
    to the base floor

    When beyond the setting time and there is no inside-call and outside-call ,elevators automatically return to the base station and wait for Passenger.

    5

    Shaft parameters
    of self-tuning

    Before the first run, system must self-learn the well parameters. Including the story on each floor, forced deceleration switch, limit switch position.

    6

    Staircase lock
    function

    In automatically run state, after the elevator locked, the system eliminates all calls registered and then return to elevator-locked base station then open the door. After that the elevator stops running, closing the light and fan in car.

    7

    Full load by pass

    Under the condition of run automatically without the driver, when the car with full load the elevator does not respond to outside-calls in passing floor. However, this time outside-calls can still be registered; it will be serviced next run-time.

    8

    Car location
    automatically
    correct

    When the elevator run to the end station ,the system automatically inspection and rectification of the location information based on the first level forced deceleration switch. At the same time, assisted by a special rate of forced deceleration.

    9

    Lighting, fan
    energy-saving
    function

    When beyond the setting time and there is no inside-call and outside call the elevator will automatically turn off the light and fan in car.

    10

    Hall call display by bit

    System allows the display of each floor using the 0-9, as well as any letters of permutation and combination of characters for use of the special conditions.

    11

    Full selective

    When the elevator running in automatic or driver state will be responded to inside-call signal meanwhile responded to outside-call button signals, any service floor can call the elevator by register the up and down signal.

    12

    Car arrival chime

    After the elevator arrival at the destination floor in accordance with the requirements of Passenger, the car roof board sent the signal.

    13

    Overload
    protection

    When the lift when the load over the rated load; elevator alarm, stop the run.

    14

    Light curtain
    protection

    When something block in the middle of the door during the door is closing, the light curtain protection action then the elevator turn to open the door. But the light curtain protection does not work in the fire operation.

    15

    CPU fault
    protection

    System has three CPUs to judge state each other, if there is abnormal, the system block all output.

    Optional Function

    NO.

    Function Name

    Descriptionof functions

    1

    Maintenance
    operation

    Elevator access to the overhaul state, the system automatically canceled and the operation of automatic doors. By the upper (lower) line will enable the elevator button to overhaul the speed of movement of the point (down) operation. Release the button to stop the lift immediately.

    2

    The best curve
    generated
    automatically

    Systems automatically computing the most suitable for the principle of human-machine function curve according to the distance needed to run, and is not subjected to restrictions on short floor and the number of constraints.

    3

    Fire back to the base station

    Receive the fire signal, the elevator will not respond to any calls and inside command. The elevator run the fastest way to the fire station and then open the door and stop.

    4

    Automatic back
    to the base floor

    When beyond the setting time and there is no inside-call and outside-call ,elevators automatically return to the base station and wait for Passenger.

    5

    Shaft parameters
    of self-tuning

    Before the first run, system must self-learn the well parameters. Including the story on each floor, forced deceleration switch, limit switch position.

    6

    Staircase lock
    function

    In automatically run state, after the elevator locked, the system eliminates all calls registered and then return to elevator-locked base station then open the door. After that the elevator stops running, closing the light and fan in car.

    7

    Full load by pass

    Under the condition of run automatically without the driver, when the car with full load the elevator does not respond to outside-calls in passing floor. However, this time outside-calls can still be registered; it will be serviced next run-time.

    8

    Car location
    automatically
    correct

    When the elevator run to the end station ,the system automatically inspection and rectification of the location information based on the first level forced deceleration switch. At the same time, assisted by a special rate of forced deceleration.

    9

    Lighting, fan
    energy-saving
    function

    When beyond the setting time and there is no inside-call and outside call the elevator will automatically turn off the light and fan in car.

    10

    Hall call display by bit

    System allows the display of each floor using the 0-9, as well as any letters of permutation and combination of characters for use of the special conditions.

    11

    Full selective

    When the elevator running in automatic or driver state will be responded to inside-call signal meanwhile responded to outside-call button signals, any service floor can call the elevator by register the up and down signal.

    12

    Car arrival chime

    After the elevator arrival at the destination floor in accordance with the requirements of Passenger, the car roof board sent the signal.

    13

    Overload
    protection

    When the lift when the load over the rated load; elevator alarm, stop the run.

    14

    Light curtain
    protection

    When something block in the middle of the door during the door is closing, the light curtain protection action then the elevator turn to open the door. But the light curtain protection does not work in the fire operation.

    15

    CPU fault
    protection

    System has three CPUs to judge state each other, if there is abnormal, the system block all output.
